Maximising Profit Through Enhanced Productivity

Products

Kundig Master – Wide belt sander

Kundig Master – Wide belt sander

Primary functions:

Sanding individual Faces – Calibrating solid, doors or base board, finish sanding of solid timber frames and veneers, denibbing lacquer in one or multiple passes.

Key features:
  • Sanding size: Extremely large sanding size considering the overall machine dimension.
  • Touch screen: Effortless touchscreen control for all adjustments.
  • Enormatic: Fully automatic quick setting and feed release.
  • Constant Pass Line: Top moving heads, the raising and lowering of the sanding units enable thicknessing of the product. With infeed and outfeed tables if required at a constant level.
  • Health & Safety: Superb health and safety features.
  • Single Button Startup: Single-button cascade start-up and highly efficient motors.
  • Sanding weight: Heavy board can be sanded due to the fixed table.
  • Heavy duty: Heavy-duty steel framed body

Adjustment: Electric compensation of the abrasive belt grain thickness.

Basic spec:

2 or 3 units / 1350mm wide x 200mm max deep. / 3-15m per minute feed speed  / 1350x2000mm sanding belt dimension /  The superb Enormatic setting system / Touch screen technology assists the operator / 18.5kw single motor / electronic compensation for the belt grit..

Read more

CUBE 3 – Four side planer

CUBE 3 – Four side planer

Primary functions:

Four-sided planing – Taking a sawn piece of timber and in one pass plane all 4 faces and straighten.

Key features:
  • Planing size: Extremely large planing size considering the overall machine dimension.
  • Touch screen: Very simple touchscreen control for all adjustments.
  • Laser preview: Lasers previewing the sawn material before planing.
  • Health & Safety: Superb health and safety features with entrance gate and workpiece monitoring.
  • Single Button Startup: Single-button start-up and highly efficient motors.
  • Dust extraction port: One dust extraction port and specially designed cutter block hoods.
  • Heavy duty: Heavy-duty durocem body
  • Can be repositioned: The Cube 3 can be repositioned in the workshop using a pallet truck.
  • Weinig Easylock knives: (add details here)
Basic spec:

4 units / 260 x 160mm max / 15 x 8mm min  / 2m straightening table / Touch screen for auto setting / throwaway tip knives on standard Weinig tooling.

Read more
